SMWD5000 Super Microwave Digestion System^NEW!

The SMWD5000 is appliable for the digestion of some samples such as food, medicines, cosmetics, as well as being widely utilized in fields such as soil analysis, geology, and polymer research. Its innovative design of pre-pressurization and a single reaction chamber effortlessly fullfills the specific needs of complex samples that require ultra-high temperatures and pressures, thereby enabling the successful digestion of the difficult-to-digest samples.

Get a Quote Online Inquiry Send E-mail PDF Download

Please leave your E-mail address before download the product PDF. Your cooperation is appreciated.

Warm prompt: Please make sure you entered a correct E-mail address. We will send you relevant information and product quotation regularly.

Features
Specifications
Spare parts
Case

The SMWD5000 is a super microwave digestion system with a single reaction chamber. With the innovative design concept, it is an epoch-making product in the field of sample digestion, which simplifies the microwave digestion process while significantly reduces the operational cost.

High Automation:
1. Patended automatic cover and closing design, improving work efficiency.
2. Automatic cooling, pressure relief, and cover opening and closing for keeping the operator away from high pressure.
3. Sealed cover and locking device made of ultra0thick duplex stainless to ensure pressure resistance and reliability of the chamber.
4. Designed with safety interlock to ensure the safety of SMWD5000 and personnel.

High Reliability:
1. Equipped with various racks for digestion tubes of 6*60ml, 8*35ml, 18*15ml and 24*8ml.
2. Compatible with digestion tubes made of quartz and TFM.
3. All digestion tubes are under the same digestion condition to ensure consistency of result.

Optimized Design:
1. Thermocouple is adopted to measure the internal temperature of digestion tubes directly, which is rapid and accurate.
2. Bucket-type symmetrical and single reaction chamber, which is introduced with the microwave transmission system in the field of microwave plasma to ensure the consistency of digestion.
3. Designed with spiral-type cooling of circulating water to rapidly cool down the chamber.
4. Program-controlled prepressurization to avoid the occurrence of sample explosion during the heating process.

Model	SMWD5000
Heating Method	Microwave heating with symmetrical single chamber
Microwave Transmission Method	Excitation cavity,wave guide,and antenna
Microwave Output Power	0-1.5kW
Temp.Measurement Method	By thermocouple
Temp.Control Range & Precision	0-500℃, ±0.1℃
Pressure Control Range	0-20MPa
Pressure Monitoring Method	Dual monitoring with mechanical pressure gauge and pressure sensor
Reaction Bucket Material	PTFE or TFM
Reaction Rack Size	6,8,18 and 24
Cooling Method	Spiral-type cooling of circulating water
Working Conditions	Ambient Temperature:5-40℃
Working Conditions	Ambient Humidity (RH):15-85%
Power Supply	200V,50-60Hz, 2kW
Net Weight	90kg
Dimensions(L×W×H)	460×600×430mm
